FDSteels HEA and HEB beams are produced using premium-grade steel with precise dimensional accuracy and consistent mechanical properties, ensuring reliable structural performance and long service life in challenging environments.
H-Beams Specifications
We provide HEA and HEB steel beams in a wide range of sizes and
technical specifications:
Beam Types: HEA / HEB
Standard: EN 10025 / DIN Standards
Steel Grades: S235JR(St37), S275JR(St44), S355JR(St52)
Size Range: 100 mm – 1000 mm
Length: 12 m
| HEA Beam Weight Table | |||||
|---|---|---|---|---|---|
| Size | Beam Height H (mm) | Flange Width B (mm) | Web Thickness D (mm) | Length A (cm) | Beam Weight (kg) |
| 100 | 96 | 8 | 5 | 100 | 200 |
| 120 | 114 | 8 | 5 | 120 | 240 |
| 140 | 133 | 8.5 | 5.5 | 140 | 296 |
| 160 | 152 | 9 | 6 | 160 | 364 |
| 180 | 171 | 9.5 | 6 | 180 | 426 |
| 200 | 190 | 10 | 6.5 | 200 | 510 |
| 220 | 210 | 11 | 7 | 220 | 610 |
| 240 | 230 | 12 | 7.5 | 240 | 720 |
| 260 | 250 | 12.5 | 7.5 | 260 | 820 |
| 280 | 270 | 13 | 8 | 280 | 920 |
| 300 | 290 | 14 | 8.5 | 300 | 1050 |
| 320 | 310 | 15.5 | 9 | 300 | 1170 |
| 340 | 330 | 16.5 | 9.5 | 300 | 1260 |
| 360 | 350 | 17.5 | 10 | 300 | 1350 |
| 400 | 390 | 19 | 11 | 300 | 1500 |
| 450 | 440 | 21 | 11.5 | 300 | 1680 |
| 500 | 490 | 23 | 12 | 300 | 1860 |
| 550 | 540 | 24 | 12.5 | 300 | 1992 |
| 600 | 590 | 25 | 13 | 300 | 2140 |
| HEB Beam Weight Table | |||||
|---|---|---|---|---|---|
| Size | Beam Height H (mm) | Flange Width B (mm) | Web Thickness D (mm) | Length A (cm) | Beam Weight (kg) |
| 100 | 100 | 10 | 6 | 100 | 240 |
| 120 | 120 | 11 | 6.5 | 120 | 320 |
| 140 | 140 | 12 | 7 | 140 | 400 |
| 160 | 160 | 13 | 8 | 160 | 500 |
| 180 | 180 | 14 | 8.5 | 180 | 590 |
| 200 | 200 | 15 | 9 | 200 | 730 |
| 220 | 220 | 16 | 9.5 | 220 | 850 |
| 240 | 240 | 17 | 10 | 240 | 998 |
| 260 | 260 | 17.5 | 10 | 260 | 1120 |
| 280 | 280 | 18 | 10.5 | 280 | 1240 |
| 300 | 300 | 19 | 11 | 300 | 1400 |
| 320 | 320 | 20.5 | 11.5 | 300 | 1530 |
| 340 | 340 | 21.5 | 12 | 300 | 1600 |
| 360 | 360 | 22.5 | 12.5 | 300 | 1700 |
| 400 | 400 | 24 | 13.5 | 300 | 1860 |
| 450 | 450 | 26 | 14 | 300 | 2050 |
| 500 | 500 | 28 | 14.5 | 300 | 2250 |
| 550 | 550 | 29 | 15 | 300 | 2400 |
| 600 | 600 | 30 | 15.5 | 300 | 2550 |
Main Types of Export H-Beam
• HEA Beam
• HEB Beam
Difference Between HEA & HEB Beams:
HEA Beams
HEA beams are lightweight wide flange beams designed for efficient structural support while reducing overall steel weight. They are commonly used in commercial buildings, warehouses, and medium-load structural systems.
HEB Beams
HEB beams feature thicker flanges and webs, providing higher loadbearing capacity and superior structural strength for heavy-duty industrial and infrastructure applications.
Key Features of HEA & HEB Steel Beams
High Structural Strength
HEA and HEB beams offer exceptional load-bearing performance, making them ideal for large-scale construction and heavy engineering projects.
Excellent Stability
Wide flange design improves structural stability and resistance against bending and deformation under heavy loads.
Long Service Life
Manufactured from high-quality structural steel, these beams provide reliable long-term performance in demanding industrial environments.
Versatile Construction Solution
HEA and HEB beams are suitable for a wide range of structural and industrial applications due to their adaptability and engineering efficiency.
Easy Fabrication & Installation
The beams are easy to weld, cut, drill, and assemble, helping improve construction efficiency and project timelines.
Cost-Effective Structural Material
Their strength-to-weight efficiency reduces material consumption while maintaining high structural performance.
Applications
Our HEA and HEB steel beams are widely used in:
• Commercial Buildings
• Industrial Structures
• Steel Construction Projects
• Warehouses & Factories
• Bridges & Infrastructure
• Power Plants
• Heavy Equipment Structures
• High-Rise Buildings
• Transportation & Railway Projects
• Oil & Gas Facilities
• Crane Systems & Industrial Platforms
Why Choose FDSteels for supply H-Beams?
• Reliable Global Export Supply
FD Steels provides organized export coordination and dependable logistics support for international buyers across CIS, GCC, Asia, and African markets.
• Consistent Industrial Quality
We maintain strict quality control standards to ensure every beam meets international structural and industrial requirements.
• Competitive Pricing
Our efficient global supply network allows us to provide cost-effective structural steel solutions without compromising quality.
• Professional Customer Support
We focus on building long-term business relationships through transparent communication, responsive service, and reliable delivery management.
FDSteels; your business partner for supplying premium quality of H- Beams (HEA – HEB) from Iran.
As a reliable business partner for our customers, we are ready to supply and export all kinds of H-Beams with premium quality, competitive prices and acceptable services. Now, contact us to get the best consult and offers.
